Anisotropic Conductive Acrylic Transfer Tape - 2 mils (50 micron)
Product Reference: U891
Scapa U891 is an electrically conductive acrylic transfer tape, supplied with a 76# polycoated release liner.
Colors: Grey
Adhesive: Electrically Conductive
Liner: White Polycoated paper
Carrier: None
Thickness: 0.05 mm
Availability: Asia/EU/NA
Currently available in all regions, subject to supply considerations.
Applications
- EMI / RFI shielding.
Product Benefits
- Service temperature: -40°C to +150°C continuous (+180°C peak).
- Service temperature: -40°F to +302°F continuous (short term: 356°F).
- Moisture resistant polycoated liner prevents wrinkling.
- Adheres to a variety of surfaces including metals, painted surfaces, and many plastic films.
- Good chemical resistance.
- High shear strength.
- Moderate initial tack, building to higher adhesion levels with increasing dwell time.
- Excellent Z direction conductivity.
